Specifications
- Chipset: INTEL H610
- CPU: Support Intel Core 14th / 13th / 12th Gen Processors, Intel Pentium Gold and Celeron Processors
- CPU Socket: LGA 1700
Memory
- 2x DDR4
- Maximum Memory Capacity: 64GB
- Memory Support: DDR4 1866 / 2133 / 2400 / 2667 / 2800 / 2933 / 3000 / 3066 / 3200 MHz by JEDEC
- Supports Dual-Channel mode
- Supports non-ECC, un-buffered memory
Onboard Graphics
- 1x HDMI
- HDMI 1.4 with HDR
- Maximum Resolution: 4K 30Hz
- Available only on processors featuring integrated graphics
- Graphics specifications may vary depending on the CPU installed
Slot
- 1x PCI-E x16 slot
- 1x PCI-E x1 slot
- PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
- PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
Audio
- Realtek ALC897 Codec
- 7.1-Channel High Definition Audio
Storage
- 1x M.2
- M.2_1 Source (From Chipset) supports up to PCIe 3.0 x4
- Supports 2280 / 2260 / 2242 devices
- 2x SATA 6G
USB
- 4x USB 2.0 (Rear)
- 4x USB 2.0 (Front)
- 2x USB 5Gbps Type A (Rear)
- 2x USB 5Gbps Type A (Front)
LAN
- Realtek RTL8111H Gigabit LAN
Internal IO
- 1x Power Connector (ATX_PWR)
- 1x Power Connector (CPU_PWR)
- 1x CPU Fan
- 1x System Fan
- 2x Front Panel (JFP)
- 1x Chassis Intrusion (JCI)
- 1x Front Audio (JAUD)
- 1x TPM pin header (Support TPM 2.0)
- 4x USB 2.0 ports
- 2x USB 5Gbps Type A ports
LED Feature
- 4x EZ Debug LED
Back Panel Ports
- HDMI
- USB 2.0
- USB 5Gbps Type-A
- LAN port
- Audio Connectors
- USB 2.0
Operating System
- Support for Windows 11 64-bit
- Windows 10 64-bit
PCB Info
- mATX
- 200mm x 236.16mm
