Specifications
Stand
-
Stand type: H shape fixed stand
-
Tilt: -5°~15°
-
Swivel: N/A
-
Pivot: N/A
-
Height adjustable: N/A
-
Quick release: Support
Structure
-
Net weight: 5.9kg ±5%
-
compatible adjustable stand: YES
-
Machine size: 615.1*373.9*574.0mm ±3mm
-
VESA: 100mm *100mm
Display
-
Size: 27 inch
-
LCD(Brand): CSOT
-
Model: SG270AB02-5 V6.1
-
Backlight: ELED
-
Panel type: Fast VA (1500R)
-
Screen ratio: 16:9
-
Resolution: 1920*1080
-
Original Refresh rate: 240Hz
-
Overclock: /
-
Viewing angle: 178°/178°
-
Active Area: 597.888mm(H)X336.312mm(V)
-
Pixel pitch: 0.1038(H) x 0.3114(V)
-
Brightness: 400cd/M²
-
Contrast: 4000:1
-
Color gamut CIE 1976:
-
NTSC: 86%
-
sRGB: 99.97%
-
DCI-P3: 95.5%
-
-
Color accuracy: N/A
-
Color temperature: 6500/7500/9300K
-
Color depth: 1.07B (8bit+FRC)
-
Response time: 2ms (OD)
Interface
-
Chipset: HT6315-EHDH
-
OD: Support
-
Input: x1 HDMI 2.1TMDS FHD240Hz, x1 DP1.4 FHD240Hz
-
Audio-out: x1 Support
-
Speaker: x2 8Ω 3W
Power management
-
Internal/External: External
-
Power Requirements: 12V/4A
-
Default power consumption: 43W
-
Power consumption(Max): 48W
-
Standby power: ≤0.5W
Features
-
KVM: Not Supported
-
ALLM: Not Supported
-
VRR: Not Supported
-
PIP/PBP: Not Supported
-
Adaptive sync: Support
-
Flicker-Free: Support
-
HDR 10: Support
-
FPS/RTS: Support
-
24.5″ Mode: Not Supported
-
Low blue light: Support
-
MPRT: Support(1ms)
-
USB Upgrade: Not Supported
Accessories
-
Video Cable Included: DP cable
-
Power Cable: Adapter 12V/4A
-
User manual: yes
-
Kensington Lock: yes
-
Stand / Base: yes
-
Others: N/A
Usage environment
-
Storage temperature: -20°C~60°C
-
Operation temperature: 0°C~40°C
-
Working humidity: 10~90%RH
-
Applicable altitude: ≤5000m
