Tech Specs
General Information
- Panel Size : 23.8″
- Aspect Ratio : 16:9
- Panel Type : VA
- Contrast Ratio (Typ.) : 4000:1 (TYP)
- Resolution : 1920 × 1080
- Refresh Rate : 144Hz (Overclock to 180Hz)
- Display Area (H × V) : 527.04 × 296.46 mm
- Backlight Type : ELED
- Curvature : R2800
- Viewing Angle : 178° / 178°
- Brightness (Typ.) : Max 250 (±20) cd/m²
- Display Colors : 16.7M
- Response Time : 12ms (Typ. GTG), OD 4ms, MPRT 0.5ms
- HDR Support : Yes (HDR Function)
- Flicker-free : Yes
Video Features
- Color Gamut : 72% NTSC / 99% sRGB / 78% Adobe RGB / 78% DCI-P3 (±3 tolerance), 8-bit
- Game Visual : Yes
- Sync Technology (VRR) : FreeSync / Adaptive-Sync
- Low Blue Light : Yes
- FPS / RTS Game Mode : Yes
- VRR : Yes
- ALLM : Yes
- Crosshair Assistant : Yes
I/O Ports
- DisplayPort : Yes (DP 1.4)
- HDMI : Yes (HDMI 2.1)
- Headphone Jack : Yes (3.5mm Output)
- Speaker : Yes (4Ω 2W × 2)
Power
- Power Consumption : 36W
- Power Off Mode : ≤0.5W
- Power Input : DC 12V 3A
Mechanical Design
- VESA Wall Mounting : 75 × 75 mm
- Tilting Angle : Forerake 5° (±3°) / Lean-Back 15° (±3°)
Accessories
- Power Adaptor
- HDMI Cable
- User Manual (QR Code Card)
- Stand Screw
