Specifications
- Model : ROG Rapture GT-BN98
Network Standard
- WiFi 8 (802.11bn) (Draft)
- IEEE 802.11bn (Draft)
- IPv4
- IPv6
Product Segment
- BN25000 ultimate BN performance : 1376+5764+5764+11529 Mbps
WiFi Data Rate
- 2.4GHz BN: 4×4 (Tx/Rx) 4096 QAM 20/40MHz, up to 1376Mbps
- 5GHz-1 BN: 4×4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbps
- 5GHz-2 BN: 4×4 (Tx/Rx) 4096 QAM 20/40/80/160MHz, up to 5764Mbps
- 6GHz BN: 4×4 (Tx/Rx) 4096 QAM 20/40/80/160/320MHz, up to 11529Mbps
Antenna
- External antenna x 8
Transmit / Receive
- 2.4GHz 4×4
- 5GHz-1 4×4
- 5GHz-2 4×4
- 6GHz 4×4
Processor
- 2.6GHz quad-core processor
Memory
- 256 MB Flash and 2 GB RAM
Boosts Speed
- OFDMA (Orthogonal Frequency Division Multiple Access)
- 4096-QAM high data rate
- 20/40/80/160/320 MHz bandwidth
Operating Frequency
- 2.4 GHz
- 5 GHz
- 6 GHz
Operating Mode
- Router(AiMesh router), AiMesh node, Access point, Repeater, Media bridge
I/O Ports
- 1 x 10Gbps for WAN/LAN
- 1 x 2.5Gbps for WAN/LAN
- 1 x 10Gbps for LAN
- 3 x 2.5Gbps for LAN
- 1 x RJ45 10/100/1000Mbps for LAN
- 1 x USB 3.2 Gen1
- 1 x USB 2.0
Buttons
- WPS Button
- Reset Button
- Power Switch
- LED control Button
LED Indicator
- WAN(Internet)
- 10G LAN
- LAN
- 6GHz
- 5GHz-1
- 5GHz-2
- 2.4GHz
- Power
Power Supply
- AC Input : 110V~240V(50~60Hz)
- DC Output : 12V with max. 5A current / 19.5V with max. 3.33A current
Package Content
- GT-BN98 Quad-band gaming router
- RJ-45 cable
- Power adapter
- Quick Start Guide
- Warranty card
Product Weight (g)
- 2070
Product Dimensions
- 350.41*350.41*220.60
AiMesh
- AiMesh
- • Primary AiMesh Router
- • AiMesh Node
Game
- Game Boost / Acceleration
- Mobile Game Mode
- Gear Accelerator
- GTNet
- ROG_First
- OpenNAT (Game Profile)
- Gaming Port
- Gaming Network
Parental Control
- Web & Apps Filters
- Time Scheduling
- Reward
- Parental Control Customized Internet Schedule
- • Maximum Parental Control Profile : 64
- • Maximum Parental Control Content Filter Rule : 64
Guest Network
- Support Guest Network Pro
- Maximum Guest Network Rule : 2.4 GHz + 5 GHz +6 GHz : 5
- Guest Network Connection time limit
- Guest Network Pro Encryption : Open system, WPA/WPA2/WPA3 Personal
- VPN WiFi
- Time Scheduling: One Time Access
- Time Scheduling: Weekly Schedule
- AP Isolate
- AiMesh Assign
- Bandwidth Limiter
- Client List
- DNS Server Connection
Security
- AiProtection
- VPN
- WiFi Encryption : WPA/WPA2/WPA3 Personal
- WPA/WPA2/WPA3 Enterprise
- Open System & OWE
- WPS
- Let’s Encrypt
- DNS-over-TLS
- SSH
- Security Scan
- Firewall
- • Maximum Firewall Keyword Filter : 64
- • Maximum Firewall Network Service Filter : 32
- • Maximum Firewall URL Filter : 64
AiProtection
- AiProtection
- • Router Security Assessment
- • Malicious Sites and Infected Device Blocking
- • Two-Way IPS
- • Advertisement Blocking
- • Tracker Blocking
VPN
- Instant Guard
- VPN Client L2TP
- VPN Client Open VPN
- VPN Client PPTP
- VPN Client WireGuard
- VPN Server IPSec
- VPN Server Open VPN
- VPN Server PPTP
- VPN Server WireGuard
- VPN Fusion
- Support Surfshark
- Support Nord VPN
Traffic Control
- Adaptive QoE
- • Bandwidth Limiter
- — Maximum Bandwidth Limiter Rule : 32
- Traffic Monitor
- • Real-time Traffic Monitor
- • Wired Traffic Monitor
- • Wireless Traffic Monitor
- Traffic Analyzer
- • Traffic Analysis Period : Daily, Weekly, Monthly
- • Website History
WAN
- Internet Connection Type : Automatic IP, Static IP, PPPoE, PPTP, L2TP
- Dual WAN
- WAN Aggregation
- 3G / 4G LTE Dongle
- 4G / 5G Auto Mobile Tethering
- Port Forwarding
- • Maximum Port Forwarding Rule : 64
- Port Triggering
- • Maximum Port Triggering Rule : 32
- DMZ
- DDNS
- NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough,PPPoE relay
LAN
- DHCP Server
- IPTV
- LAN Link Aggregation
- Manually Assign IP Address
- • Maximum Manually Assign IP Address Rule : 128
- Wake on LAN (WOL)
- VLAN
Wireless
- MU-MIMO
- UTF-8 SSID
- WiFi MAC Address Filter
- • Maximum MAC Filters : 64
- Wireless Scheduler
- WiFi insight
- Airtime Fairness
- RADIUS Client
USB application
- 4G / 5G Auto Mobile Tethering
- File System : HFS+, NTFS, vFAT, ext2, ext3, ext4
- Safely Remove Disk
- Media Server
- Samba Server
- FTP Server
- Shared Folder Privileges
User Interface
- WEB: ASUSWRT
- APP: ASUS Router APP
- Operating system : ASUSWRT
Administration
- Configuration Backup and Restore
- Diagnosis Tools
- Feedback System
- System Log
- New Device Connect Notification
- Login Captcha
- Connection Diagnosis
- Auto Firmware Update
